ไฮไลท์
• Designed to meet IEC 61010-1 CAT III 600V
• Test leads with remote control switch.
(For insulation&Simplified Earth Test)
• Back light function.
• Color coded scales and range switch position for easy reading.
• Automatic warning when resistance of auxiliary earth spikes is in excess of tolerance.
• Can be hung around the neck for both hand’s operation.
ข้อมูล
น้ำหนัก
บาร์โค้ด
ลงสินค้า
อัพเดทล่าสุด
รายละเอียดสินค้า
Insulation Testing
Test Voltage 250V/50MΩ
500V/100MΩ
1000V/2000MΩ
Accuracy ±5%rdg
Earth Resistance
Simplified Precision
measurement
12Ω/120Ω/1200Ω
Accuracy ±3% of full scale value
AC Voltage
0-600V AC ±3% of full scale value
Earth Voltage
0-60V AC ±3% of full scale value
Safety Standard IEC 61010-1 CAT III 600V Pollution Degree 2
IEC 61010-2-031
IEC 61557
Power source LR6 (1.5V) × 8
Dimensions 130(L) × 183(W) × 100(D)mm
Weight 1000g approx.
Included Accessories 7103A (Test leads with remote control switch),
7131B (Safety crocodile clip [black]), 7161A (Flat test prod [black])
8017 (Extension prod), 9092 (Cord case), 9121 (Shoulder strap),
Battery LR6 (1.5V) × 8, Instruction Manual
Optional Accessories 7100A (Precision measurement Cord Set)
8016(Hook type prod)
