FA667 POWER AMP OCL 100+100W STEREO R1% ลงปริ้นท์

Product Description
In applications requiring a high powered stereo amplifier the FK667 features a twin powerful Class AB 100Wrms outputs to do the job. Users will add a preamplifiers, mixers, and tone controls to complete the system in accordance with their individual requirements for public address, home entertainment, emergency and office applications.
Technical Specification


Power Supply : +50V 0V -50V @ more than 6 Amps
Frequency Response : 10hz-100KHz
Input Sensitivity : 1Vrms
Input Impedance : 15KOhm
Output Power : 100Wrms+100Wrms into 4 or 8 Ohms.
Total Harmonic Distortion : 0.02%
PCB Dimensions : 4.5" x 3.56" x 3.0" (114.3mm x 90.4mm x 76.2mm)
